Dust collector / Bag dust filter
If you need help please contact us!
Factory direct sales:Yes
Delivery method:Sea/land
Product introduction Bag-Type dust remover is a kind of dry dust filter device,It is suitable for trapping fine, dry and non fibrous dust.In recent years, due to the emergence of new synthetic fiber filter material, the continuous improveme
- +8613607653853
- 7*24 hours service hotline
Product introduction
Bag-Type dust remover is a kind of dry dust filter device,It is suitable for trapping fine, dry and non fibrous dust.In recent years, due to the emergence of new synthetic fiber filter material, the continuous improvement of ash removal method and the use of automatic control and detection device make the pulse dust collector develop rapidly, which has become the most competitive dedusting equipment in all kinds of high-efficiency dedusting equipment.
Bag-Type dust remover is a kind of dry dust filter device,It is suitable for trapping fine, dry and non fibrous dust.In recent years, due to the emergence of new synthetic fiber filter material, the continuous improvement of ash removal method and the use of automatic control and detection device make the pulse dust collector develop rapidly, which has become the most competitive dedusting equipment in all kinds of high-efficiency dedusting equipment.
Technical Data of the Dust collector / Bag dust filter
| Model | QM | QM | QM | QM | QM | QM | QM | QM | QM |
| 32-3 | 32-4 | 32-5 | 32-6 | 64-4 | 64-5 | 64-6 | 64-7 | 64-8 | |
|
Volume of processed Air (m3/h) |
6900 | 8930 | 11160 | 13390 | 17800 | 22300 | 26700 | 31200 | 35700 |
|
Filter wind speed (M/min) |
0.8-2.0(Customize according to technological conditions) | ||||||||
|
Total filtration Area (m2) |
93 | 124 | 155 | 186 | 248 | 310 | 372 | 434 | 496 |
|
NET filtration area (m2) |
62 | 93 | 124 | 155 | 186 | 248 | 310 | 272 | 434 |
|
Number of filtration rooms |
3 | 4 | 5 | 6 | 4 | 5 | 6 | 7 | 8 |
|
Total number of filter bags |
96 | 128 | 160 | 192 | 256 | 320 | 384 | 448 | 512 |
|
Resistance Dust (PA) |
1470-1770 | ||||||||
|
Concentration of inlet gas dust (g/Nm3) |
<200 | ＜1000 | |||||||
|
Concentration of exhaust gas dust (g/m3) |
<0.1 | ||||||||
|
Pressure on the body of the dust collector (Pa) |
5000 | ||||||||
